RS-M42B1
Realsaw
| Specification: | |
|---|---|
| Material: | Please select |
| Quantity: | |
| Model NO. | RS-M42B1 |
| Product Name | High Quality M42 Bimetal Band Saw Blades for Cutti |
| Material | High Speed Steel & Spring Steel |
| Specifications | 13mm/19mm/27mm/34mm/41mm/54mm/67mm/80mm |
| Specification | 27mm*0.9*10/14 T |
| Origin | China |
| Production Capacity | 1000000m/Year |
| Type | Band Saw Blades |
| Cutting Application | Carbon Steel/Alloy Steel/Die Steel/Stainless Steel |
| Hardness | HRC68-69 |
| Transport Package | Pallets/Cartons/Wooden Cases |
| Trademark | Realsaw |
| HS Code | 8202201000 |
1. The world's advanced oil quenching and continuous tempering technologies extremely improved the hardness of the tooth and the wear resistance of backing material,which made those 2 different materials into perfect performance.
2.Special heat-treatment technology solved the problems of knife bend and S bend.The straight band saw blade improved the quiet running property and the effect of saw cutting.
3.The equal teeth height and sharpness are better than traditional gear milling technology and the glossiness made for the easily chip removal.
4.The precise upsetting technology imporved the glossiness and geometric tolerance.
5.Sepcial design of cutting edge and angle suits different alloy material's saw cutting.
| M42 Bimetal band saw blades list | ||
| Specifications | Teeth Form | |
| 13mmx0.65 | 1/2x.025 | 10T 14T 4T 6T 6/10 8/12 10/14 |
| 13mmx0.9 | 1/2x.035 | 10T 14T 4T 6T 6/10 8/12 10/14 |
| 19mmx0.9 | 3/4x.035 | 6T 8T 10T 14T 3/4 4/6 5/8 6/10 8/12 10/14 |
| 27mmx0.9 | 1x.035 | 10/14 8/12 6/10 5/8 4/6 3/4 2/3 |
| 34mmx1.1 | 1-1/4x.042 | 8/12 6/10 5/8 4/6 3/4 2/3 |
| 41mmx1.3 | 1-1/2x.050 | 4/6 3/4 2/3 1.7/2.5 1.4/2 1/1.5 0.75/1 0.75/1.25 |
| 54mmx1.6 | 2x.063 | 3/4 2/3 1.7/2.5 1.4/2 1/1.5 0.75/1 0.75/1.25 |
| 67mmx1.6 | 2-5/8x.063 | 2/3 1.7/2.5 1.4/2 1/1.5 0.75/1 0.75/1.25 |
| 80mmx1.6 | 3x.063 | 2/3 1.7/2.5 1.4/2 1/1.5 0.75/1 0.75/1.25 |
